SIMPLIMATIC MODULAR ROBOT CELL.

Designed as a simple solution to add robotics to a manufacturing line, the Simplimatic® Modular Robotic Cell is a mounting stand for a variety of robotic systems. The cell was designed to provide ample workroom for both the robot, necessary end-eff ectors, ancillary cabling, controls, and other system-critical umbilical components.

FEATURES:

The Simplimatic® Modular Robot Cell is highly customizable, but all cells include an AllenBradley® CompactLogix PLC standard. Other frequently ordered system features include:

• Mounting for FANUC® LR Mate 200iD and R-30iB Mate Controller
• Mounting for Simpli-Flex® HD table-top Conveyor
• Mounting for Cimtrak® edge belt Conveyor
• Mild painted-steel frame with extruded aluminum and lexan guarding
• Safety interlocked front and rear access doors

Options:

The Simplimatic® Modular Robot Cell can be equipped with custom HMIs, vision systems, component in-feed systems, and application specifi c endof-arm tooling. Other common options include

• StrongArm® HMI mount with Simplimatic® Front End software
• External component tables for vibratory bowl and dispenser mounting
• Encoder-driven backlit conveyor for vision-based pick and place
• Internal cell end-eff ector storage for robotic tool changes
• SCADA software for smart industry 4.0 communication
